Solution
Features
Developed with our own LFP (lithium iron phosphate)cell to ensure the highest safety and most promising cycle life. Smart BMS protects the cell in all angels such as abnormal temperature, current, voltage, SoC, SoH
No maintenance and easy installation saves the valuable main power.
Specifications
| SPECIFICATION |
BASICPARAMETERS |
T48150 |
| Nominal |
Nominal Voltage(V) |
48 |
| Nominal Capacity(Ah) |
150 |
| Nominal Charge Current (A) |
100 |
| Nominal Discharge Current(A) |
100 |
| Physical |
Dimension(mm) |
482*420*135 |
| Weight(Kg) |
48 |
| Electrical |
Discharge Voltage(V) |
42～54 |
| Charge Voltage(V) |
52.5～54 |
| Peak Discharge Current(A) |
150@3S |
| Peak Charge Current(A) |
100@3S |
| Others |
Communication |
RS232, RS485 |
| Charging Temperature |
0℃~50℃ |
| Discharging Temperature |
-20℃~50℃ |
| Shelf Temperature |
-20℃~60℃ |
| Certification |
CE/UN38.3 |
| Design life |
10+Years(25℃177F) |
| Cycle Life |
>6000(80%DoD) |
Applications
The 150Ah Backup Power UPS Battery is suitable for a wide range of critical power applications.
Telecommunications
- Mobile base stations
- Telecom switching rooms
- Transmission stations
- Fiber network equipment
- Remote communication sites
Data Centers
- Server backup
- Network equipment backup
- Rack-mounted UPS systems
- Edge computing facilities
- Storage and processing infrastructure
Commercial Facilities
- Office network rooms
- Financial service systems
- Retail data equipment
- Security and monitoring centers
- Communication control rooms
Industrial Systems
- PLC and automation equipment
- Industrial computers
- Emergency control systems
- Process monitoring equipment
- Factory communication networks
Renewable Energy Systems
- Solar telecom stations
- Hybrid grid and solar backup
- Remote monitoring stations
- Off-grid communication equipment
Benefits for System Integrators and Project Buyers
Compact Rack Integration
The standard 3U design simplifies installation in existing telecom and server cabinets.
Flexible Voltage Selection
48V and 51.2V options support different telecom, UPS and energy storage architectures.
High Backup Capacity
The 150Ah configuration provides substantial energy storage without requiring a large floor-standing battery bank.
Intelligent Protection
The integrated BMS monitors battery status and helps prevent damage caused by abnormal operating conditions.
Reduced Maintenance
LiFePO4 chemistry reduces routine maintenance requirements compared with conventional lead-acid batteries.
Suitable for Modular Projects
Multiple units can be configured for projects requiring longer backup duration or higher energy capacity.
Customizable System Integration
Voltage, communication, terminal layout, cabinet integration and monitoring requirements can be configured according to the project.
Installation Requirements
The battery should be installed by qualified electrical or energy storage personnel.
Before installation, confirm:
- UPS or rectifier voltage compatibility
- Charging voltage range
- Maximum charging current
- Maximum discharge current
- Communication compatibility
- Rack dimensions and load capacity
- Cabinet ventilation
- Cable size and cable length
- DC breaker or fuse rating
- Correct positive and negative polarity
- Grounding requirements
- Local electrical and fire safety regulations
The battery should be installed in a dry, clean and ventilated location away from direct sunlight, heat sources, standing water and corrosive substances.
Adequate space should be reserved for cable connection, inspection and battery removal.
It is designed for telecom networks, data centers, server rooms, industrial control systems and other facilities where continuous power availability is essential.
For project selection, send us your UPS model, system voltage, connected load, required backup time, communication protocol and order quantity. We can recommend a suitable battery configuration for your backup power system.
