Triton 3665 38.4V 65Ah LiFePO4 Marine Battery
Triton 3665 38.4V 65Ah LiFePO4 Marine Battery

Triton 3665 38.4V 65Ah LiFePO4 Marine Battery

The Triton 3665 is a 38.4V 65Ah LiFePO4 marine battery for compatible trolling motors and onboard applications. It lists 2.496kWh nominal energy, active cell balancing and Bluetooth communication.

Request a Configuration →  |  Explore Related Batteries

  • Marine-grade Safety

  • IP67 Protection

  • Active Balancing

  • Multiple Protection

COMPACT. RUGGED. READY.

IP67-rated protection for harsh marine conditions

60A continuous discharge, up to 120A for 5 seconds

Active BMS with cell balancing and multiple protections

5-year warranty for reliable long-term performance



DIMENSIONS



Triton 3665 LifePo4 Marine Battery





SPECIFICATIONS
Rated Voltage 38.4 V
Voltage Range 30.0–43.2 V
Rated Capacity 65 Ah (2.496 kWh)
Continuous Discharge Current 60 A
Peak Discharge Current ≤120 A for 5 seconds
Continuous Charge Current 60 A
Discharge Temperature -20°C to 60°C
Charge Temperature 0°C to 55°C
Cell Balancing Active Balancing
Communication Bluetooth
IP Level IP67
Cell Type LiFePO4
Weight Approx. 19.5 kg

Key Features of Triton 3665 36V 65Ah LiFePO4 Marine Battery

Wiren Triton 3665 is a 38.4V 65Ah LiFePO4 marine battery designed for compatible trolling motors, fishing boats, and onboard electrical applications. With 2.496kWh energy capacity, IP67 protection, active cell balancing, and Bluetooth monitoring, this lithium marine battery provides a compact power solution for marine applications.

Explore more Motive LiFePO4 Battery Solutions from Wiren for different marine and mobile power requirements.

  • LiFePO4 Technology: Provides stable performance for marine battery applications.
  • 65Ah Capacity: Delivers 2.496kWh nominal energy for compatible onboard loads.
  • IP67 Protection: Provides protection against dust and water ingress under specified test conditions.
  • Active Cell Balancing: Helps maintain battery cell balance during operation.
  • Bluetooth Monitoring: Allows users to check battery operating information through a compatible mobile device.

36V Lithium Battery for Trolling Motors and Boats

Triton 3665 is designed for compatible 36V-class trolling motor systems and marine electrical applications. Its 65Ah capacity provides stored energy for electric fishing boats, small boats, and other onboard equipment.

This 36V 65Ah trolling motor battery is suitable for applications where compact size, reduced battery weight, and reliable power delivery are important. Before installation, check the trolling motor's voltage, continuous current, and peak current requirements against the battery specifications.

IP67 Protection and Smart Battery Management

Marine batteries operate in environments exposed to moisture, splashes, and changing conditions. Triton 3665 features an IP67-rated enclosure for additional protection against dust and water ingress.

Its battery management system combines active cell balancing and Bluetooth monitoring to support battery status management. Users can check relevant battery information and monitor operating conditions through a compatible device.

LiFePO4 vs. Traditional Lead-Acid Marine Batteries

Compared with traditional lead-acid marine batteries, LiFePO4 marine batteries offer several practical advantages:

  • Lower Weight: Helps reduce the battery weight carried onboard.
  • Maintenance: Does not require routine electrolyte maintenance like flooded lead-acid batteries.
  • Battery Management: Integrated BMS technology supports battery monitoring and protection.
  • Charging Performance: Supports efficient charging when used with a compatible charger.

These advantages make lithium deep cycle marine batteries a practical option for fishing boats and electric trolling motor applications.

How to Choose the Right 36V Marine Battery

Before purchasing a 36V lithium marine battery, consider the following factors:

  • Motor Voltage: Confirm compatibility with the 36V-class electrical system.
  • Continuous Current: Check that the motor's operating current does not exceed the battery's 60A continuous discharge rating.
  • Peak Current: Verify that the motor's startup and peak current requirements are within the battery's specified limits.
  • Capacity: Select the appropriate Ah rating according to expected operating time.
  • Charging Compatibility: Use a charger suitable for the battery's LiFePO4 chemistry and voltage.

Frequently Asked Questions About Triton 3665 Marine Battery

1. Is Triton 3665 a 36V or 38.4V Marine Battery?

Triton 3665 has a nominal voltage of 38.4V and is designed for compatible 36V-class marine electrical systems.

2. Can Triton 3665 Power a 36V Trolling Motor?

It can be used with compatible 36V trolling motors. Check the motor's continuous and peak current requirements against the battery's discharge ratings before installation.

3. What Does IP67 Protection Mean for a Marine Battery?

IP67 indicates dust-tight protection and protection against temporary immersion in water under specified testing conditions. It does not mean the battery is designed for permanent underwater use.

4. Can I Monitor Triton 3665 Through Bluetooth?

Yes. Triton 3665 supports Bluetooth monitoring, allowing users to check available battery operating information through a compatible mobile device.
